Aluminium Angle Flange (48.3mm) - Kee Lite (L67-8)
Aluminium Angle Flange (48.3mm) - Kee Lite (L67-8) Aluminium Angle Flange (48.3mm) - Kee Lite (L67-8)

Aluminium Angle Flange (48.3mm) - Kee Lite (L67-8)

from only £47.15 (ex.VAT) £56.58 (inc.VAT)
Average: reviews






Available to buy
Add To Basket
Product Code:L67-8
Bulk Discounts ex. VAT inc. VAT
Order 1 to 25 Tube Clamps  £50.50 £60.60
Order 26 to 49 Tube Clamps  £48.80 £58.56
Order 50+ Tube Clamps   £47.15 £56.58
View more:


Aluminium Angle Flange (48.3mm) - Kee Lite (L67-8)

The Type L67 has been designed to allow the upright to pivot in the barrel, providing an angular displacement from 3° up to a maximum of 11°, measured from the vertical. Ideal to secure balustrade and guardrail systems on access ramps or other types of slopes . Ø indicates the diameter of the fixing hole. This aluminium tube clamp is to be used with 48.3mm alloy or steel tube.

These aluminium tube clamps are great for use in harsh enviroments (like marine work), as they are corrision resistant, and controlled enviroments like clean-rooms etc... They can also be used as an alternative to fabrication to construct all-aluminium structures, and are also useful for building temporary or portable structures like trade show stands, banner stands, for staging or lighting rigs etc... as they are extremely lightweight.

  • Lightweight
  • Corrosion Resistant
  • Require little long term maintenance
  • Fitted with Stainless Steel recessed grub screws
  • Main fittings are TÜV approved





Measurements (mm)



Size

Code

D

E F G H

Weight (kgs)

48.3mm

L67-8

102

160 115 90 9

0.50



Info

Detail

Manufacturer

Kee Lite

Material

Aluminium

Allen Key Size

3/4

Weight

0.50kg
